Dental 20:1 Reduction Implant Contra Angle Handpiece: Surgical Low Speed Contra-Angle Compatible with NSK Ti-Max X-SG20L Series
$ 34.11
Item Number: SX3100
- High-Torque 20:1 Reduction Gear Train: Machined from ultra-hard, wear-resistant medical steel substrates. The precision-engineered gear array down-converts micro-motor velocity with absolute mechanical stability, delivering consistent, non-stalling rotational force (>80N·cm) for dense cortical bone preparation. Modular Detachable Head & Capsule Structure: As showcased in the overhaul breakdown, the entire head capsule and drive shaft can be separated from the main ergonomic body. This modular design lets technicians targetedly swap out worn internal cartridges or transmission rods without forcing full-handpiece decommissioning. Integrated Rigid External Irrigation Hook: Outfitted with a heavy-duty, fixed-position external cooling tube hook. It guides sterile saline lines directly to the surgical site without obstructing the clinician’s field of view, preventing thermal jawbone injury during osteotomy procedures. Hermetic Double-Sealing Fluid Barrier: Engineered with a specialized multi-level sealing gasket layout at the chuck interface and capsule base. This prevents physiological fluids, bone dust, and saline back-bleeding from infiltrating the gear transmission core, completely avoiding premature corrosion. 134°C Autoclavable Thermo-Stability: Every structural alloy, gear axis, and internal seal is built to endure rigorous chemical line-purging treatments and continuous thermal sterilization processing up to 134°C (273°F), retaining original dimensional tolerances over heavy operational lifespans. ⚙️ Engineering Procurement & SKU Configuration: Customize your batch directly via our drop-down interface to match specific clinical or bench workshop requirements as depicted in asset: Complete Handpiece Assembly: 1 Full 20:1 Reduction Surgical Implant Contra Angle Handpiece (Ready for immediate motor adaptation). Replacement Modular Head & Capsule Kit: Complete detachable head housing pre-fitted with the internal torque-reduction cartridge core. Internal Core Drive Shaft Component: The central mechanical gear transmission axis, ideal for repairing handpieces suffering from internal slipping or gear grinding. Technical Specifications Feature / Attribute Technical Details Product Platform Class Professional 20:1 Gear-Reduction Dental Implant Surgical Handpieces System Cross-Compatibility Fully Compatible with NSK Ti-Max X-SG20L & Standard E-Type Motors Transmission Gear Ratio 20:1 Exact Reduction Profile (High-Torque / Low-Speed Outer Output) Chucking Mechanism Heavy-Duty Push-Button Surgical Chuck with Strict Retention Springs Max Operational Torque Verified up to 80 N·cm under Heavy Surgical Loading Cooling Architecture Fixed External Saline/Water Spray Line Configuration Sterilization Parameters 100% Autoclavable up to 134°C (273°F) / Thermal Distortion Safe ? Handpiece Repair Workshop Bench Guide: To preserve gear meshing integrity and prevent immediate drive shaft binding: The Alignment Press Protocol: When reinstalling the detachable head or replacing the internal drive shaft gear axis, ensure the internal drive splines are perfectly lined up with the micro-motor receiving slot before tightening the retaining ring. Forcing the threads when gears are misaligned will immediately strip the teeth, causing severe mechanical damage. Surgical Saline Cleaning Purge: Because surgical implant procedures rely heavily on saline cooling, salt crystals will build up inside the gear capsule if not properly maintained. Technicians must instruct clinical users to run the handpiece with distilled water for 30 seconds immediately after surgery, followed by thorough lubrication before autoclaving. This prevents salt accumulation from locking up the reduction gears.
