Dental Chair Air Water Filter Regulator AF2000-02: Turbine Handpiece Moisture Trap Separator with Manual Drain & Fitting Joints
$ 8.91
Item Number: SX3100
- Micron-Grade Sintered Bronze Filter Element: Hidden inside the clear polymer shield rests an advanced, porous sintered bronze filtration cartridge. This media delivers excellent multi-stage physical interception, forcing incoming supply lines to shed aerosol water droplets, particulate scale, and carbon tracking without restricting critical working cubic-feet-per-minute flow rates. Dual Condensate Management Frameworks: To accommodate diverse engineering layouts and clinical preferences, this module is available in two distinct bowl archetypes: Non-Drain Variant (Sealed Bottom): Features a completely enclosed, solid-base clear reservoir, providing a leak-free setup for units tied to downstream automatic auto-purge drain traps. Manual Push-Drain Variant (Pin-Valve Base): Integrated with a top-mounted knurled brass release crown and lower spring-loaded pin valve. This layout allows technician field crews or staff members to purge collected fluid pools instantly with a single upwards thumb stroke. Authentic AF2000-02 Engineering Matrix: Built strictly around the precision specifications of the industry-standard AF2000-02 plumbing architecture. It reliably sustains an ultra-smooth pneumatic working envelope spanning between 0.005MPa and 0.85MPa (0.05 – 8.5bar), ensuring delivery lines stay perfectly balanced even through unpredictable utility pressure spikes. Comprehensive Array of Premium Fitting Adapters: Available with tailored, micrometer-machined brass and chrome-plated connection nodes configured specifically to accept common 8mmx5mm,8mmx5.5mm and 6mmx4mm polyurethane water/air hoses with absolute zero-leak security: 90°C Angled Elbow Barb Joints: Prominently featured on the intake/outflow ports, these heavy-gauge forged brass elbows allow tight line drops inside shallow floor enclosures without line crimping. Pneumatic Blue Lock-Collar Push-In/Quick-Tight Joints: Highlighted along the manifold line, these fittings allow rapid, tool-free connection and disconnection during diagnostic checkouts. Complete Turnkey Mounting Accessories Bundle: Every individual filter regulator assembly ships fully equipped with its own custom-stamped anti-corrosive structural metal mounting bracket and a pair of matching machine anchoring screws (as itemized at the base, ensuring rigid installation behind access panels right out of the box. Technical Specifications Matrix Product Classification: Dental Chair Utility Hardware / Handpiece Turbine Protection Air Filters Chassis Metallurgy & Composition: Hardened Anodized Aluminum Alloy Block High-Transparency Shatterproof Polycarbonate Bowl Universal Part Footprint ID: Model AF2000-02 Framework Pneumatic Operational Tolerances: Operating Pressure Envelope: 0.005 – 0.85MPa (0.05 – 8.5Bar) Filter Porosity Threshold: Universal multi-stage micro particulate capture rating Available Pipeline Hose Configurations: Outer Diameter 8mmx Inner Diameter 5mm (Optimized for standard utility feed-lines) Outer Diameter 8mmx Inner Diameter 5.5mm (High-flow utility layout) Outer Diameter 6mmx Inner Diameter 4mm (Compact auxiliary branch logic lines) Primary Target Operational Workflows: Upgrading Floor Junction Box Filter Arrays, Protecting Turbine Handpiece Bearings from Moisture Corrodents, Replacing Crushed Polycarbonate Filter Bowls, General Overhaul of Treatment Chair Main Air Supply Networks ? Field Service Engineer Installation & Configuration Protocol: Clinical Pressure Interruption Safety Action: Turn off the main water and air supply valves that feed into the dental chair assembly. Open the 3-way syringe on the delivery unit to bleed off any remaining line pressure until the internal manifold gauges rest completely at 0psi. Mounting Bracket Setup & Line Alignment: Take the included stamped metal bracket and secure it firmly to the internal chassis rail inside the junction box using the provided twin screws. Thread your chosen connection adapters (Elbow or Straight Push-In, depending on your line pathing layout) into the filter block ports using high-grade PTFE thread tape. Manifold Interception & Leak Verification: Align your incoming supply hose with the “IN” port arrow on the aluminum manifold housing, and connect the handpiece feed line to the opposite “OUT” side. Press or clamp the tubing firmly into place until it sits fully flush with the fittings. Slowly turn on your utility air valves, watch the transparent bowl to confirm the system builds pressure without any hissing micro-leaks, and step on your foot controller to verify that your turbine handpieces receive clean, dry, properly filtered air flow.
