Universal Dental Chair Delivery Unit Handle: Instrument Tray Plastic Handle Replacement with Pneumatic Air Lock Button Valve
$ 16.11
Item Number: SX3100
- Triple Structural Configuration Profiles: Engineered to support a wide range of global dental chair brands, ensuring hassle-free compatibility for field technicians through three distinct mounting profiles: Style A (Extended Bracket Base): Designed with a dual-screw lateral mounting bracket recess for seamless fastening along structural side-rails. Style B (Threaded Column Barrel): Features a clean, axial cylindrical receiver sleeve with precision internal threading for direct rod-mount integrations. Style C (Angular Top-Mount Collar): Utilizes an angled bracket head profile with an open top-locking port alignment to suit specific modern aesthetic delivery configurations. Instant Pneumatic Brake Response Valve: Every handle option includes a heavy-duty mini brass push-button pilot valve (shown adjacent to the handles across. It delivers immediate, leak-free airflow regulation to release your mechanical tension arms without stiffness or lag. Dual-Barb Miniature Fitting Matrix: The included brass valve cartridge features precision dual-barb connection nipples. This design lets you slide standard 3×2mm or micro pilot air tubes directly over the barbs, securing an airtight seal that easily handles constant utility pressure line spikes. Withstands Chemical Surface Disinfection: Constructed from cross-linked industrial polymers that are structurally unreactive to common operatory chemical agents, surface disinfectants, and alcohol barrier wipes. This ensures the handles stay completely free from surface stickiness, stress fractures, or yellowing. Smooth Ergo-Contoured Tactile Grip: The lower sweeping grip profile provides excellent anti-slip ergonomics. This shape distributes pulling forces evenly across the clinician’s palm, reducing hand strain during long, demanding restorative or surgical procedures. Complete Turnkey Installation Hardware: Each handle package includes a custom-stamped stainless steel locking washer and matching brass terminal nut components, giving field technicians everything they need for quick, wobble-free mounting right out of the box. Technical Specifications Matrix Product Classification: Dental Chair Equipment Hardware / Instrument Tray Grip Handle Replacements Chassis Metallurgy & Composition: Medical-Grade Impact-Resistant ABS Polymer Machined Solid Brass Valve Cores Mounting Interface Selection: Style A: Dual-Screw Lateral Mounting Extension Frame Style B: Concentric Cylindrical Internal Thread Sleeve Style C: Angled Top-Mount Collar Profile with Single-Bolt Lock Hole Air Switch Valve Framework: Dual-Barbed Micro Pneumatic Push-Button Valve Standard Component Finish: High-Gloss Dental Office Clean White Maximum Mechanical System Pressure: Valve rated for standard pilot air systems up to 0.5MPa Primary Target Operational Workflows: Upgrading Worn Delivery Trays, Replacing Defective Brake Push-Buttons, Customizing Over-the-Patient Delivery Unit Arms, General Field Service Chair Overhauls ? Field Service Engineer Installation & Configuration Protocol: Pneumatic Isolation Safety Action: Disconnect the central air compressor line supplying the dental unit. Bleed off any remaining pilot line pressure by repeatedly pumping the foot controller and existing tray switches until the system gauges drop to zero. Old Grip Demounting & Line Routing: Loosen the mounting fasteners or thread sleeve that secures the old worn handle to the tray housing. Carefully slide the assembly away to expose the underlying micro polyurethane hoses. Label and pull the air lines free from the old barbed valve nodes. New Handle Integration & Locking Procedure: Select the proper matching handle model (Style A, B, or C, as shown in the design specs). Secure the micro lines firmly over the dual brass barbs until they sit completely flush. Mount the handle shell onto the tray chassis, making sure to drop the stainless steel locking washer into position before tightening the anchor screws or collar sleeve. Re-pressurize the dental unit and test the thumb button to verify that the pneumatic brake releases and locks smoothly without air leaks.
