Universal Dental Cuspidor Drain Assembly: Spittoon Plastic Waste Collector Kit with Horizontal Side Drain Outlet & Cover Cap
$ 8.91
Item Number: SX3100
- 90°C Space-Saving Horizontal Side Outlet: Features a precision-molded right-angle discharge spout (prominently extending to the lower right. This side-drain layout is highly valued by technicians working inside compact dental chair lateral cabinets or ultra-shallow console shells where traditional vertical straight drops are blocked by electrical control boxes, hydraulic lift blocks, or water line manifolds. Dual-Stage Fluid Barrier & Anti-Splash Shroud: Outfitted with a premium, smooth-contoured white protective cover cap held by sturdy vertical alignment pillars. This cover blocks patients’ line of sight into the drain, dampens evacuation line gurgling, and creates an effective downward spray baffle to prevent cross-contamination splashback during aggressive bowl-rinse cycles. Modular Multi-Piece Optimization Compatibility: Engineered as a universal core platform that can be packaged as a 4-piece standard essential kit or a 5-piece extended plumbing combo. It accommodates varied sub-basin accessories including micro-perforated internal strainer baskets, rubber compression washers, locknuts, and flexible corrugated waste hoses, making it easy to build tailored SKUs for different repair scenarios. Ultra-Smooth Anti-Adhesion Internal Boring: The interior pathways and curves of the collection chamber are finished with a mirror-polished glaze technique. This ultra-slick profile stops calcified biomaterials, temporary restorative fragments, prophy paste sludge, and biological waste from sticking to the walls, preventing foul-smelling bacterial biofilms and line blockages. Secure Stepped Barb Coupler Interface: The horizontal exit tube is shaped with a subtle outer barb ring (as seen at the lower nozzle. This shape creates a firm, slip-free bite when joined to flexible drainage hoses, allowing a watertight seal with standard hose clamps or heavy-duty vinyl solvent sleeves. Technical Specifications Matrix Product Classification: Dental Chair Waste Infrastructure Fittings / Cuspidor Spittoon Drainage Replacement Kits Chassis Plastic Composition: Medical-Grade Chemical-Resistant Engineering ABS / Polypropylene Compound Drain Exit Path Configuration: 90°C Horizontal Lateral Flow Output Structural Assembly Build Options: 4-Piece System Core: Shroud Cover Cap, Internal Strainer Basket, Main Collection Base, Structural Sealing Gasket 5-Piece System Core: Adds a specialized flexible corrugated extension tube or stepped conversion adapter Chemical Exposure Ratings: Full structural resistance to surgical aspiration cleansers, bleaching agents, alcohol solutions, and enzymatic compounds Primary Target Operational Workflows: Replacing Cracked Under-Basin Spittoon Catch Cups, Modifying Straight Down-Drains to Side-Cabinet Layouts, Overhauling Treatment Unit Evacuation Basins, Eliminating Floor Box Drain Odors, General Clinic Facility Maintenance ? Field Service Engineer Replacement & Installation Protocol: Clinic Sanitation & Disinfection Protocol: Flush the target cuspidor basin with a generous dose of anti-microbial evacuation system solution to disinfect the underlying lines. Shut off the automatic rinse water solenoids and place a collection bucket inside the chair’s side cabinet directly beneath the old drainage joint. Old Housing Extrusion & Basin Port Cleaning: Reach inside the cabinet shell and unthread the plastic locking collar that secures the old drain body to the underside of the ceramic spittoon basin. Push the old assembly up and out of the basin port hole. Clean away any old silicone caulk, mineral scale, or organic residue around the porcelain mounting seat until it is completely smooth. New Collector Seat Integration & Flow Validation: Check the rubber seal ring position on your new side-drain assembly base. Push the new assembly threads firmly up through the basin opening from below, and spin the lower mounting nut until it locks tight against the ceramic wall. Connect your flexible waste pipe to the barb nozzle, making sure to position the horizontal outlet toward your primary floor drain channel. Slide the internal strainer basket into place, snap on the anti-splash protective top cover cap, run a full basin flush cycle, and verify that wastewater discharges rapidly with absolute zero leakage at the joints.
